Mini-Circuits’ TRS2-1T-75+ is a 75Ω surface-mount balanced-to-balanced transformer with a 2:1 secondary/primary impedance ratio covering the 5 to 1200 MHz band, meeting bandwidth requirements for DOCSIS® 3.1 compliant systems and equipment, among other applications. This model provides 1.0dB insertion loss, 20dB return loss, 0.3dB amplitude unbalance and phase unbalance from 0.8˚ to 5˚. It is capable of handling RF input power up to 0.25W and DC current up to 30mA. Measuring only 0.28×0.25×0.12”, the unit features core and wire, all-welded construction with gold over nickel plate wraparound terminations suitable for tin/lead and RoHS solder systems. The unit also includes Mini-Circuits TopHat™ feature for faster, more accurate pick-and-place assembly.
